BOLDATA® VFX 551A-T (SYS-551A-T)
BOLData® VFX 551A-T
The VFX 551A-T Series Workstations provide the best platform for your VFX needs and are capable of rendering incredible 3D models and animations with whisper quiet operation.
Key Features
- Single Intel Xeon W-3500/3400 Processor
- Up to 2TB ECC DDR5, 16 x RDIMM
- Up to 1 quad-width or 1 triple-width or 4 double-width or 4 single-width GPUs
- Tower/5U Rackmount Chassis, 4 x 3.5" / 2 x 2.5" internal drive bays (opt.)
Configured price $4,701.00
Intel® Xeon® Processors
Workload-Optimized Performance and Power Efficiency Gains
Get more compute and faster memory at the same power envelope as our previous generation, plus outsized performance and TCO in AI, HPC, database, networking, and storage.
Intel Xeon processors are optimized to deliver new levels of performance across the greatest range of workloads, while offering improved efficiency and lower power consumption.
Reduce Costs With Improved Performance Per Dollar In The Cloud With Intel Xeon Processors
With their superior performance for data-intensive operations, advanced memory capabilities, and integrated security features, Intel Xeon processors provide a robust platform for enterprises to navigate the complexities of the modern cloud environment.
Optimize Your Data Center With Intel Xeon Processors For TCO Savings
Consolidate workloads to fewer servers and repurpose space and power for AI-ready servers at a lower total cost without compromising performance. Make the best use of your space, power, and budget.
Discover How To Best Refresh And Scale Your Data Center
Intel® Xeon® Processor Advisor Suite can help determine the best solutions for your workload whether it's refreshing existing infrastructure or building a new data center. Get instant recommendations and optimize based on TCO, sustainability and power.
DDR5—Packing Power and Performance into a New Generation
Increased Banks and Burst Length
DDR5 doubles the banks from 16 to 32. This allows for more pages to be open at a time, increasing efficiency. Also doubled is the minimum burst length to 16, up from 8 for DDR4. This improves data bus efficiency, providing twice the data on the bus, and consequently reduces the number of reads/writes to access the same cache data line.
Improved Refreshes
DDR5 adds a new command called SAME-BANK Refresh, which allows a refresh of just one bank per bank group, versus all banks. When compared to DDR4, this command allows DDR5 to further improve on performance and efficiency.
Decision Feedback Equalization
DDR5 utilizes Decision Feedback Equalization (DFE) to provide stable, reliable signal integrity on the module, required for high bandwidth.
Single processor(s)
Intel® Xeon® W-3500/W-3400 processors
Up to 60C/128T
Supports up to 350W TDP CPUs (Air Cooled)
Slot Count: 16 DIMM slots
Max Memory (2DPC): 2TB 4800MT/s ECC DDR5 RDIMM/LRDIMM
SATA: SATA (6Gbps) via Intel® C790
Drive Bays Configuration
Default: Total 6 bays
4 internal fixed 3.5" NVMe*/SATA drive bays
2 front fixed 2.5" SATA drive bays
(*NVMe support may require additional storage controller and/or cables)
M.2
4 M.2 PCIe 5.0 x4 NVMe slots (M-key 2280/22110)
Peripheral Bays
2 5.25" bays
1 RJ45 10GbE with Marvell® AQC113
1 RJ45 1GbE with Intel® I210-AT
Form Factor: Tower or 5U Rackmount
Weight and Dimensions:
Height: 21.06" (535 mm)
Width: 8.74" (222 mm)
Depth: 22.56" (573 mm)
Package: 27.8" (H) x 14.6" (W) x 28.5" (D)
Gross Weight: 39 lbs (17.74 kg)
Net Weight: 20 lbs (14.9 kg)
Default
6 PCIe 5.0 x16 FHFL slots
LAN
1 RJ45 10GbE with Marvell® AQC113
1 RJ45 1GbE with Intel® I210-AT
USB
2 USB 2.0 ports(rear)
2 USB 2.0 Type-A ports(front)
2 Type-A ports(Front)
Video
1 VGA port
Audio
Audio Jacks
TPM
Trusted Platform Module (TPM) 2.0
Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Windows® 11 Professional Edition
